Detailed Introduction
|
Laser Machine Configuration
|
|
|
|
|
Model
|
JT-3030
|
|
Laser Wavelength
|
1064
|
|
Output Power Adjustment Range
|
0-100%
|
|
Laser Repetition Frequency Range
|
20KHz-200 KHz
|
|
Engraving Depth
|
0.01mm-0.5mm (depending on material)
|
|
Beam Quality
|
M2: <1.3
|
|
Output Beam Diameter
|
7mm
|
|
Output Method
|
Single-mode laser pulse output
|
|
Operating Power Supply
|
24V
|
|
Engraving Speed
|
≤7000mm/s
|
| Repeat Positioning Accuracy |
≤
±
0.001mm
|
|
Engraving Range
|
300*300mm
|
|
Scanning Angle
|
±25°
|
|
Maximum Incident Beam Diameter
|
≤10mm
|
|
Minimum Line Width
|
0.01mm
|
|
Minimum Character Height
|
0.15mm
|
|
Engraving Content
|
Realizes Chinese and English text, date and time, barcodes, serial numbers, QR codes, designed graphics, numbers, and letters.
字母等的标记。
|
|
Font Library Types
|
Complete font library functions, up to 200 fonts (expandable), customizable fonts, and creation of proprietary fonts.
字库。
|
|
Overall Operating Power Supply
|
AC220V±10%/50Hz
|
|
Overall Power
|
≤1000W
|
|
Continuous Operating Time
|
24 hours
|
